Y80612 - Laird Professional Grade Gold Anodized 806-896Mhz 12 Element 11dBd Yagi Antenna
Gold anodized, fully welded Laird Yagi
|
IN STOCK
UPC : Y80612
Manufacturer: TE Connectivity (Laird)
Manufacturer Part No: Y80612
* Whole number only
|
The main benefit of the Laird Yagi antenna is its ability to focus its signal in one direction leading to the greater gain figures. This antenna is designed for use on stationary objects such as buildings. If this antenna is not correctly aimed, it will lose its effectiveness. Why Laird Yagi's are the Industry's Finest: - Super high durability fully welded and gold anodized - will not oxidize and are highly weather resistant
- Internal matching design will not ice up, detune or corrode
- Broad bandwidth allows gain performance to be more consistent through the frequency range
- Forward gain optimized by computer analysis and then field-tested for conformance
- Hand tuned on a network analyzer for best power match and lowest VSWR yielding the best possible performance every time
Does not include pole/mast - see FMW4-YMST4: Laird 4' x 1-1/4" Aluminum Mast and 4" Standoff Wall Mounts (2 Brackets) Specifications | | Part Number | Y80612 | | Frequency Range | 806-896MHz | | Antenna Gain | 14dBi | | Elements | 12 | | Radiation | Directional | | Connector | N Female | | Mount | Pole (not included) w/U-Bolts |
LMR-400 N/Male to N/Male Extensions Cables: |
Finished cable with N Male ends.
Ultra low loss jumper for connecting amplifier to splitter or lightning suppressor
|
Ultra low loss cable for runs over 20'. Finished cable with N/Male ends.
|
Ultra low loss cable for runs over 20'. Finished cable with N/Male ends.
|
List Price: $79.99
Your Price: $74.99
You Save: $5.00 (6 %)
50' of 50-Ohm, low-loss, black WILSON-400 COAX cable; N-Male to N-Male.
|
|
Ultra low loss cable for runs over 20'. Finished cable with N/Male ends.
|
Y80612 - Laird Professional Grade Gold Anodized 806-896Mhz 12 Element 11dBd Yagi Antenna
|
|
